Commodity :  Phosporic acid  chemical pump

Pump Case: Cast iron Lined with Fluoroplastic alloy (F46)

Impeller : Cast Iron Lined with Fluoroplastic Alloy (F46)

Base Plate: Cast Iron

Technology :

It is metal casing lined with teflon (FEP) , impeller and pump cover integrally sintered and pressure

molded by metal inserts with teflon outside ,

Externally mounted bellows mechanical seal for shaft seal , stationary seal ring made of 99.9%

Aluminum oxide ceramics or Silico Carbide ,rotating seal ring made of tetra fluoride packing materials or SIC .

It resists corrosion ,abrasion ,high temperature and aging ,and has high mechanical strength ,no toxin decompounding ,and wide

range of service temperature.

Application :

It is widely used in the industries of chemical ,pharmaceutical ,pesticides and wastewater treatment.

performance range :

Operated temperature :  -20- 120 degree.C

Flow capacity :  3.6 m3/h to 200m3/h

Pump head : 20-80m


Model NO: IHF50-32-125F
Q: 12.5m 3/h
H: 20 m
N: 2.2kw

if you have any comment,please let us to know.
